PCE FRPC-18
High-performance polycarboxylate slump retention agent
Download product file
-
Appearance
Colorless or Yellowish Liquid
-
Density(g/cm3)
1.03±0.02
-
pH
3.0~4.0
-
Solid content
≥50±1, can be customized
-
Sample
Free
-
Stock Status
Custom Order
Product Description
FRPC-18 is a high-performance polycarboxylate superplasticizer produced by C6 technology. It is designed based on special ionic functional groups and molecular conformation. With steric hindrance and strong electrostatic repulsion, FRPC-18 can effectively improve the adsorption and dispersion ability of superplasticizer and its adaptability to concrete raw materials. and has the advantages of moderate water reduction rate, excellent plastic retention and small slump loss. At the same time, with the continuous hydration of cement, more carboxyl groups can be released to disperse cement particles continuously, and the concrete has the advantages of excellent plastic retention and small slump loss. The water reduction rate of concrete is≥25%, and the highest water reduction rate in concrete is 50% of FRPC-02. If a concrete with a slump of 130mm is required to be held for 1 hour to 3 hours, a concrete with a slump of 160-180mm is held for 1 hour to 3 hours, and a concrete with a slump of 220mm is held for 1 hour to 4 hours, the technical specifications can be reached by adjusting the formula using FRPC-18. It is widely used in hydropower, nuclear power, railway, highway, port, bridge, tunnel, house, workshop floor, underground structure construction and other concrete projects. The technology is very mature and the product quality is stable. You are welcome to compare its performance with the product you are using.
Product Type
| The contents of the products available | |||
| Name | Solid content | ||
| Liquid products (FRPC-18) | 40% | 50% | 55% |
| Powder product (FRPD-18) | 98% | ||
| PCE Product Type | |
| No. | Type |
| FRPC-02 | polycarboxylates high performance water-reducing admixture |
| FRPC-09 | comprehensive properties polycarboxylate superplasticizer |
| FRPC-18 | high-performance polycarboxylate slump retention agent |
| FRPD-02 | polycarboxylates high performance water-reducing admixture powder |
| FRPD-09 | comprehensive properties polycarboxylate superplasticizer powder |
| FRPD-18 | high-performance polycarboxylate slump retention agent powder |
Formula
Taking the temperature of 30℃and 1.0Kg(L)/100Kg cement as an example, the following formula test can be used when the slump of concrete is required to be maintained at 220mm for 3 hour:
| Product Compounding Formula | ||||||
| Material | Dosage（kg） | Notes | ||||
| Formula 1 | Formula 2 | Formula 3 | Formula 4 | |||
| FRPC-02（40%） | 300-400 | 100 | / | / | There are clear ways to use different amounts of PCE in these formulations, Please contact our company for detailed communication. | |
| FRPC-09（40%） | 80-150 | 180-300 | / | / | ||
| FRPC-18（40%） | 100-150 | 150-200 | / | / | ||
| FRPD-02（98%） | / | / | 125-163 | 41 | ||
| FRPD-09（98%） | / | / | 33-61 | 73-123 | ||
| FRPD-18（98%） | / | / | 41-61 | 61-82 | ||
| Sodium gluconate | 20-40 | 20-40 | 20-40 | 20-40 | It depends on the temperature and setting time | |
| Sucrose | 5-10 | 5-10 | 5-10 | 5-10 | It depends on the temperature and setting time | |
| Other special materials | ? | ? | ? | ? | It depends on the circumstances | |
| Air Entraining Agent | 1.2-1.8 | 1.2-1.8 | 1.2-1.8 | 1.2-1.8 | If there is no requirement for gas content, the lowest value can be taken | |
| Deodorant | 0.3 | 0.3 | 0.3 | 0.3 | You can use it in two days and you don't have to add it | |
| Water | Add water to 1000Kg | Clean water | ||||
| The data is for reference only, and the specific formula should be determined by test. | ||||||
Prefabricated buildings and components
Prefabricated buildings and components
Prefabricated buildings and components
Technology Service
Concrete technology, concrete admixture technology welcome consultation:
WhatsApp：13783184240
WeChat：FLR13783184240
Email：[email protected]
[email protected]
TEL：13783184240
Product specification
| Items | Standard |
| Appearance | Colorless or Yellowish Liquid |
| Density(g/cm3) | 1.03±0.02 |
| pH | 3.0~4.0 |
| Solid content | ≥50±1, can be customized |
| alkali content (Na2O+0.658K2O %) | ≤10.0 |
| chloride content (%) | ≤0.2 |
| sodium sulfate content(%) | ≤10.0 |
| Fluidity of cement paste (mm) | ≥120 |
